ASUS Server- ESC4000-E10
Resourch: ENERGYUNI-IPC Platform AddDate: 2021-11-19 [back] Views:
Feature
- Total 11 x PCIe 4.0 Expansion Slots in 2U Server
- 4 x PCIe 4.0 x16 link for dual-slot GPU cards or 8 x PCI-E 4.0 x8 link for single-slot GPU cards.
- 8 x 3.5”/2.5” Hot-swap Storage bays (up to 8 x NVMe drive support)
- OCP 3.0 support (optional)
Target market- Streaming Media
- Cloud Computing
- Virtualized & VDI Application
- Enterprise & HPC Application
Intel® Xeon® Scalable Platform Design
ASUS ESC4000-E10 is built on the 3rd Generation Intel® Xeon® Scalable Processors with more core density compared to previous generation in dual sockets to increase server utilization.
Flexible Design and Performance
- Supports up to 4 x PCIe Gen 4.0 dual-slot GPU cards or 8 x PCIe Gen 4 single-slot GPU cards, and 3 x PCIe Gen4 slots for low-profile network adapters or other expansion cards.
- OCP3.0 Mezzanine slot option for added networking flexibility.
- Capacity for 8 x 3.5“ / 2.5’’ hot-swap storage bays. Max. 8 x storage bays can be configured to support NVMe drives.
Comprehensive IT infrastructure management solution
ASUS ESC4000-E10 features an embedded ASMB10-iKVM (BMC, AST2600) and is bundled with ASUS Control Center to provide comprehensive out-of-band and in-band management capability.
Specifications
Processor Dual socket P+ (LGA 4189) 3rd Generation Intel® Xeon® Scalable Processors Support (up to 205W) Memory Total Slots 16 (8-channel per CPU) Capacity Up to 2TB Memory Type DDR4 3200/2933 RDIMM Intel® Optane™ Persistent Memory Memory Size 256GB, 128GB, 64GB, 32GB, 16GB *Please refer to www.asus.com for latest memory AVL update Expansion Slots Total Slots 11 Slot Type Rear: - 4 x PCIe x16 slots (Gen4 x16 link, FH,FL) for dual-slot GPU cards or 8 x PCIe x16 slots (Gen4 x8 link, FH,FL) for single-slot GPU cards - 2 x PCIe x16 slots (Gen4 x16 link, LP,HL) Front: - SKU-1 (default) 1 x PCIe x8 slot (Gen4 x8 link, LP,HL) 4 x M.2 sockets (Gen4 x4 link, up to 22110 module) - SKU-2 (by request) 1 x PCIe x8 slot (Gen4 x8 link, LP,HL) 1 x OCP3.0 slot (Gen4 x16 link) - SKU-3 (by request) N/A Storage Bays 8 x 2.5" or 3.5" Hot-swap Storage Bays (Backplane Supports 8 x SATA/SAS/NVMe Devices*) 1 x M.2 socket (Gen4 x4 link, up to 2280 on-motherboard) Networking LAN 2 x Gigabit LAN ports (Intel® I350-AM2) 1 x dedicated management port (BMC AST2600) Security TPM / PFR Module (optional) Front I/O Ports 4 x USB 3.2 Gen1 ports Rear I/O Ports 2 x USB 3.2 Gen1 ports 2 x Gigabit LAN ports (RJ45) 1 x Management port (RJ45) 1 x VGA port Switch/LED Front : Rear : 1 x Power Button/LED 1 x Power Button/LED 1 x Location LED 1 x Location Button/LED 2 x LAN LED 1 x Message LED 1 x Message LED 1 x HDD Access LED 1 x HDD Access LED 1 x Q-Code/Port 80 LED OS Support *Please find the latest OS support from https://www.asus.com/event/Server/OS_support_list/OS.html Management Solution Software ASUS Control Center (in-band) Out of Band Remote Management ASMB10-iKVM (out-of-band/BMC AST2600) Dimension 800mm x 440mm x 88mm (2U) 31.50" x 17.22" x 3.46" Net Weight Kg (Barebone without packing) 34 kg Gross Weight Kg (Barebone with pacling) 44 kg Power Supply 1+1 Redundant 1600W 80 PLUS Platinum Power Supply 1+1 Redundant 2200W 80 PLUS Platinum Power Supply (following different configuration by region) Environment Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing) Note *Users need to remove Slimline cables from the PCIe riser board & OCP3.0 slot board, and re-connect the cables to the backplane to support up to 8 x NVMe devices. - Preview: none
