特性
规格
处理器 | CPU | LGA1151 socket for 9th/8th Generation Intel® Core™ i9/ i7/ i5/ i3/Pentium®/Celeron® Processors |
Chipset | Intel® Q370 Chipset | |
内存 | Technology | DDR4 2666/2400/2133MHz |
Max. | 64GB | |
Socket | 4 x U-DIMM | |
显示 | Controller | Intel UHD Graphics 630/610 |
HDMI | 1, Supports HDMI 1.4 up to 4096 x 2160 @ 24Hz / 2560 x 1600 @ 60Hzz | |
Display Port | 2, Supports DP 1.2a up to 4096 x 2304 @ 60 Hz | |
D-Sub | 1, Supports up to 1920 x 1200 @ 60Hz | |
Multi Display | Dual DP +HDMI+D-SUB, DP+HDMI+D-SUB, Dual DP+HDMI, Dual DP+D-SUB, | |
扩展槽 | PCIe | 1 x PCI Express 3.0/2.0 x16 |
2 x PCI Express 3.0/2.0 x1 | ||
1 x PCI | ||
M.2 | 2 x M.2 Socket with M Key, type 2242/2260/2280 storage devices with IRST support(1@ SATA* & PCIE mode), SATA mode share with SATA6G_2. Ready for Intel® Optane Memory | |
1 x M.2 Socket with E Key, type 2230 Wi-Fi devices support | ||
以太网 | Speed | 10/100/1000Mbps |
Controller | 1 x Intel® I219LM, supports WOL/PXE | |
Connector | 1 x RJ-45 | |
音频 | Codec | Realtek® ALC887 8-channel High Definition Audio CODEC |
Connector | Line-in, Line-out, Mic-in | |
存储 | SATA port | 6 x SATA 6.0 Gb/s ports (gray), support Raid 0,1,5,10 |
后面板I/O | PS/2 | 1 x Keyboard (Purple), 1 x Mouse port (Green) |
DisplayPort | 2 | |
HDMI | 1 | |
D-SUB | 1 | |
Ethernet | 1 | |
USB | USB 3.2 Gen 2 (TypeA)x 1, USB 2.0 (TypeA) x 2 | |
Audio | 3 Audio jacks support 8 channel | |
内部连接器 | Serial Port | 2 (2 x RS 232) |
USB 3.2 Gen 1 | 2, support additional 4 x USB 3.2 Gen 1 connectors | |
USB2.0 | 1, support additional 2 x USB2.0 connectors | |
Fan header | 1CPU fan x 1, Chassis fan x 2 | |
Chassis intrusion header | 1 | |
Front panel audio header (AAFP) | 1 | |
System panel header | 1 | |
Clear CMOS jumper | 1 | |
LPC Debug header | 1 | |
LPT port header | 1 | |
Power connector | 1 x 24-pin ATX Power connector, 1 x 8-pin ATX 12V Power connector | |
Speaker connector | 1 | |
MONO-out header | 1 (with AMP IC) | |
DIS ME jumper | 1 | |
看门狗定时器 | H/W | No |
安全 | TPM | TPM 2.0 IC Onboard (NPCT750) |
电源 | Power Type | ATX power |
操作系统 | Microsoft Windows | Windows® 10 (64bit ) / Win10 IoT Enterprise |
Linux | Ubuntu, RedHat Enterprise, Fedora Workstation | |
环境 | Operating Temperature | 0~60° C |
Non-Operating Temperature | -40~85° C | |
物理特征 | Form Factor | Micro ATX, 9.6 x 9.6 inches (24.4 x 24.4 cm) |
认证 | EMI & Safety | CE, FCC |
