Processor System
|
CPU
|
Intel® Socket 1151 for 7th/6th Generation Core™
i7/i5/i3/Pentium®/Celeron® Processors supports Intel® 14 nm CPU, support max.
65W CPU
|
|
CHIPSET
|
Intel® H110 chipset
|
|
Memory
|
Technology
|
DDR4 2400/2133 MHz
|
|
Max.
|
32GB
|
|
Socket
|
2 x U-DIMM
|
|
Display
|
VGA
|
1, Supports up to Up to 1920 x 1200 @60Hz
|
|
HDMI
|
1, Supports up to 4096 X 2160 @ 24Hz (colay with DP, optional)
|
|
Dual Display
|
VGA+HDMI(Default)
|
|
VGA+DP(optional)
|
|
PCIe
|
1 x PCIe 3.0/2.0 x16 slot (x16 mode)
|
|
Expansion Slot
|
1 x PCIe 2.0 x16 slot (@x4 mode, x4pin)
|
|
PCI
|
5 x PCI
|
|
M.2
|
1 x M.2 Socket 3 with M key, type 2242/2260/2280(SATA mode)
|
|
Ethernet
|
Speed
|
10/100/1000Mbps
|
|
Controller
|
1 x Intel® i219V, 1 x Intel® I211AT
|
|
Connector
|
2 x RJ-45
|
|
Audio
|
Codec
|
Realtek ALC887-VD2 High Definition Audio
|
|
Connector
|
Line-Out, Line-In, Mic in
|
|
Storage
|
SATA port
|
3 x SATA Gen 3.0, up to 6Gb/s
|
|
Rear I/O
|
VGA
|
1
|
|
HDMI
|
1 (colay with DP, optional)
|
|
USB 3.2 Gen1
|
4
|
|
Ethernet
|
2
|
|
Serial Port
|
2(RS232/422/485)
|
|
Audio jack
|
3
|
|
PS/2
|
1 x Keyboard Port, 1 x Mouse Port
|
|
Internal Connector
|
Serial Port
|
6 (RS232)
|
|
USB2.0
|
2 x Header Support Additional 4 x USB2.0 Connectors
|
|
2 x stick socket
|
|
CPU Fan Connector
|
1 (PWM Mode)
|
|
Chassis Fan Header
|
1 (PWM+DC Mode)
|
|
Chassis Intrusion Header
|
1
|
|
Front Panel Audio Connector
(AAFP)
|
1
|
|
System Panel Header
|
1
|
|
Clear CMOS Jumper
|
1
|
|
Speaker Connector
|
1
|
|
LPC Debug Header
|
1
|
|
I2C Header
|
1
|
|
Parallel
|
1
|
|
GPIO Header
|
1 (8 Bit)
|
|
AT/ATX Select Header
|
1
|
|
Power Connector
|
1 X 4-pin ATX Power Connector, 1 X 24-pin ATX Power Connector
|
|
Watchdog Timer
|
H/W
|
YES
|
|
Security
|
TPM
|
1 x SPI TPM header
|
|
Power
|
Power Type
|
AT/ATX mode
|
|
Operating System
|
Microsoft Windows
|
Windows 7 (32/64bit) / Windows 10 (64bit ) / Win10 IoT Enterprise
|
|
Linux
|
Ubuntu, Red Hat Enterprise, Fedora Workstation, Open SUSE
|
|
Environment
|
Operating Temperature
|
0~60 ℃
|
|
Non-Operating Temperature
|
-40~85 ℃
|
|
Relative Humidity
|
0%~85%
|
|
Dimension
|
Form Factor
|
ATX, 305 x 244 mm
|
|
Certification
|
EMI & Safety
|
CE, FCC
|
