Processor System
|
CPU
|
Build in Intel® Celeron® Quad-Core J3455 SoC onboard Processors
|
|
Technology
|
DDR3L 1866/1600/1333 MHz Non-ECC, Un-buffered Memory
|
|
Memory
|
Max.
|
8GB
|
|
Socket
|
2 x U-DIMM
|
|
|
VGA
|
1, Supports up to 1920 X 1200 @ 60 Hz
|
|
Display
|
HDMI
|
1, Supports up to 3840 x 2160 @ 30 Hz
|
|
LVDS
|
1, Supports up to 1920 X 1200 @ 60Hz
|
|
Multi Display
|
HDMI+VGA+LVDS
|
|
Expansion Slot
|
PCIe
|
1 x PCIe 2.0 x4 (x1 mode)
|
|
M.2
|
1 x M.2 Socket 1 with E key, type 2230 for WIFI/BT device
|
|
|
Speed
|
10/100/1000Mbps
|
|
Ethernet
|
Controller
|
1 x Realtek® RTL8111H, supports PXE/WOL
|
|
Connector
|
1 x RJ-45
|
|
Audio
|
Codec
|
Realtek® ALC887-VD2 8-Channel High Definition Audio
|
|
Connector
|
Line-Out, Line-In, MIC
|
|
Storage
|
SATA port
|
2 x SATA Gen 3.0, up to 6Gb/s
|
|
Rear I/O
|
VGA
|
1
|
|
HDMI
|
1
|
|
USB3.2 Gen1
|
4
|
|
Ethernet
|
1
|
|
Serial Port
|
1 (RS232)
|
|
Audio jack
|
3
|
|
PS/2
|
1 x Keyboard Port, 1 x Mouse Port
|
|
Internal Connector
|
Serial Port
|
1 (RS232)
|
|
USB3.2 Gen1
|
1 X Header Support Additional 2 X USB3.2 Gen1 Connectors
|
|
USB2.0
|
2 X Header Support Additional 4 X USB2.0 Connectors
|
|
CPU Fan Connector
|
1 (PWM Mode)
|
|
Chassis Fan Header
|
1 (PWM+DC Mode)
|
|
Chassis Intrusion Header
|
1
|
|
Parallel Port Connector
|
1
|
|
Front Panel Audio Header
(AAFP)
|
1
|
|
System Panel Header
|
1(10-1 Pin)
|
|
Clear CMOS Jumper
|
1
|
|
Buzzer
|
1
|
|
LVDS Connector
|
1
|
|
Display Panel Backlight Power
Selector
|
1
|
|
Flat Panel Display Brightness
Connector
|
1
|
|
Display Panel VCC Power
Selector
|
1
|
|
LCD panel monitor switch
header
|
1
|
|
Power Connector
|
1 X 4-pin ATX Power Connector, 1 X 24-pin EATX Power Connector
|
|
Watchdog Timer
|
H/W
|
YES
|
|
Security
|
TPM
|
1 x LPC TPM header
|
|
Power
|
Power Type
|
EATX, ATX mode
|
|
Operating System
|
Microsoft Windows
|
Windows® 10 (64bit)
|
|
Linux
|
Ubuntu, RedHat Enterprise, Fedora Workstation, OpenSUSE
|
|
Environment
|
Operating Temperature
|
0~50° C
|
|
Non-Operating Temperature
|
-40~70℃
|
|
Relative Humidity
|
0%~85%
|
|
Dimension
|
Form Factor
|
Mini-ITX, 170 x 170 mm
|
|
Certification
|
Safety
|
CE, FCC
|
